XRAY X10 - 2018 SPECS - 1/10 PAN CAR GT
Manufacturer:
Xray
RC DisCo Part No:
XR370504
Out of Stock - Discontinued Product€306.72 (RRP inc. VAT)
2018 All-new Specs
- All-new chassis features ultra-narrow design for improved steering characteristics, increased torsional stability and new two-position option for pod link mounting for in-corner steering adjustment
- All-new new rear suspension with all parts redesigned and updated
- All-new narrower Pod plate
- All-new rear alu bulkheads with new clamp system for ultra-low CG and new system for multiple motor mount mounting positions
- All-new ride height adjustment via shims and eccentric upper clamps
- All-new easier motor access
- All-new rear graphite rear brace significantly reduces tweak of the rear pod and lowers CG
- All-new narrower side tubes for improved handling and reducing the weight
- All-new narrower rear link brace for shorter side tubes
- All-new lower pivot brace with nut groove for tweak-free movement
- All-new super lightweight and lowered pivot ball for lower roll center that stabilizes the car
- All-new harder front upper arms for easier handling and smoother steering
- All-new harder front upper arm mounts for easier handling of the car
- All-new upper arm position adjustment shims
- All-new steering blocks with removed excess play to improve steering response
- All-new upper ball joints with removed excess play
- All-new center shock position adjustment for steering characteristics setting
- All-new shock adaptor to extend the shock absorber
- All-new graphite plate for antenna holder
- All-new longer servo mounts to fit the mid-size servos
General
- XRAY 1/10 pan-car with authentic 100% self-developed XRAY parts, designed and manufactured parts by XRAY in Europe
- Legendary XRAY premium design, workmanship & material quality and unmatched attention to the finest details
- Simple yet effective and proven design, well thought-out details, unmatched precision of all small details
- High-competition design with focus on ultra-low weight, resulting in super-lightweight construction
- Optimized for indoor carpet racing as well as outdoor asphalt racing
Chassis
- CNC-machined from 2.5mm high-grade graphite material
- Ultra-narrow chassis designed for short battery packs improves steering response and overall traction on all track surfaces
- Increased torsional stability results in increased grip while eliminating tire scrubbing in high-speed corners, and better bump handling
- Multiple shock mounting holes allow long-shock mounting alternative for increased on-power traction and drivability over bumps
- Chassis layout designed to give sufficient stiffness for excellent handling, but flexible enough to generate sufficient grip and traction
- Battery placement in either forward or rearward position, secured by composite battery holders
- Lay-down steering servo gives lowest CG at the chassis center
- Chassis and rear pod features pre-drilled centerline holes for optimum weight balance adjustment using HUDY Balancing Tool #107880
- Robust body posts with fully-adjustable body holders; optional super fine +1 or +2mm body backstops available optionally for even more super-fine body height adjustment
Front suspension:
- High-competition, fully-adjustable front suspension with strong, smooth-operating composite parts
- Lower suspension arms feature eccentric aluminum inserts for quick & easy changing and setting of front track-width
- Optional aluminum 0.5 and 1.0mm eccentrics available for wider or narrower track-width
- Ride height adjustment shims for quick & easy precise ride height adjustment for various track conditions; set of 0.2, 0.4 and 0.6mm ride height adjustment shims included
- All composite parts manufactured by XRAY using premium self-developed composite mixtures which guarantee sufficient flex of suspension parts while being hard enough to withstand heavy impacts
- Quick & easy front caster adjustment via included clips
- Reactive front caster adjustment with preset 2.5°, 5.0° or 7.5° angles via easy-to-change eccentric bushings
- Ultra-precise wheel axles CNC-machined from premium HUDY Spring Steel™ additionally hardened and hand ground for precision fitment
- High-precision, HUDY Spring Steel™ upper pivot balls ensure super-fine movement of the front suspension under compression
- Composite lower pivot balls allow the front suspension to work more smoothly
- Front upper 3mm adjustable HUDY Spring Steel™ camber turnbuckles are lightweight yet can withstand hard impacts
Steering:
- Chassis features predrilled holes for the servo mounts on both left and right side which allows the placement of the servo to balance the car as necessary
- Super-tiny yet robust steering blocks with specially-designed axles which prevent axle spinning while tightening the wheel locking nuts
- Pivoting front suspension with super-smooth hardened steel kingpins supported by included soft springs; optional medium, hard, and extra-hard suspension springs available
- Aluminum servo mounts position the servo flat on the chassis to ensure lowest possible CG
- Tiny yet robust servo saver with easy Ackermann adjustment via shims mounted below pivot balls
- 4-spring servo saver makes the car steer more precisely and smoothly
- Specially-designed narrow composite ball joints
- Adjustable, super-lightweight Swiss 7075 T6 aluminum turnbuckles
Rear pod:
- Narrow rear pod allows for super-easy motor access, accommodating all motors
- Straight side springs improve side traction and handling, giving smoother out-of-corner exiting and reduced traction rolling
- Compact, ultra-lightweight narrow rear pod constructed from high-strength aluminum bulkheads, graphite brace, and thin-but-strong high-grade graphite plates
- Centrally-located composite rear pod links give increased steering response and improved side-to-side weight transition
- Unique alu bulkheads and upper bulkhead clamp are CNC-machined from premium extra-hard Swiss 7075 T6 aluminum, additionally black coated for long life & stylish look
- Premium-grade graphite upper deck provides solid attachment for shock absorber to rear pod
- Rear differential features high-grade precision carbide balls for spur gear, hardened and precision-ground D-steel shims, and premium carbide 3x8mm axial thrustbearing
- Ultra lightweight graphite rear axle
- Precision-molded spur gear made from XRAY's exclusive composite material, ensuring true running, super-quiet operation, super lightness and robustness for handling powerful motors
- Aluminum rear hubs machined from lightweight aircraft aluminum, specially lightened and black coated for stylish look
- Lightweight rear wheel mounting screws for reduced rotating weight
- Aluminum wheel hub with center-balanced clamping mounting system, ensures secure mounting while eliminating vibration and run-out
- Easy rear track-width adjustment via included shims
- Rear body posts are mounted to the chassis via a wide independently-mounted graphite holder, ensuring body downforce is properly transferred to the chassis
- Rear pod weight balance can be easily adjusted via shims between motor and bulkhead
Shock:
- Fully-adjustable XRAY micro shock shares similar design to its “big brother” counterpart in XRAY’s successful T4 touring car platform
- Hard-anodized aluminum shock body for ultra durability
- Fine-threaded shock body for quick & easy shock spring preload adjustment
- Tiny, thin shock membrane gives super-smooth damping characteristics
- Super-soft silicone shock O-ring for smooth operation while preventing oil leakage
- Ultra-finely finished shock shaft with precision-molded composite shock piston ensures optimum shock oil flow and smooth action
- Simple, well-designed construction allows for quick & easy shock-length adjustment for downstop adjustment
- Shock position adjustment via shimming of HUDY Spring Steel™ shock ball studs
- Shock position adjustment
- Shock length adaptor is included to alter shock length
- Rear pod side balance is controlled by side tubes which give equalized lateral damping in both directions while eliminating unwanted rebound
Assembly & support:
- Highest quality of all composite parts ensures super-precise fitment, easy assembly, and smooth operation of all parts
- Premium 3D full-color Instruction Manual (available only for download)
- Exclusive Virtual Online Setup Sheet database with thousands of set-up sheets for race tracks around the world
- Premium, unmatched XRAY online support
Adjustment possibilities:
- Front camber, wheelbase, caster, reactive caster, and toe
- Front & rear track-width
- Front, center & rear ride height
- Front springs
- Fully-adjustable rear shock absorber
- Pod lateral damping
- Downstops
- Ackermann
- Differential settings
- Wheelbase
- Shock position
- Servo position
- Weight balance
- Ackermann
- Bumpsteer
|
Dimensions |
|
|
Class: |
1/10 electric pancar |
|
Width: |
Adjustable 190mm front, 195mm rear |
|
Length: |
depends on rear tires used |
|
Wheelbase: |
255 +/- 3mm |
|
Weight: |
280g |
|
Ready-to-run weight: |
1050g - incl. BL system (varies depending on equipment used) |
|
Chassis |
|
|
Chassis: |
2.5mm carbon fiber, CNC machined |
|
Body: |
Not included, uses 1/10 pancar type |
|
Drivetrain |
|
|
Type: |
2WD direct drive to rear axle |
|
Rear Axle: |
Steel shaft with ball differential |
|
Primary: |
Spur/pinion |
|
Bearings: |
High-speed ball-bearings (10) |
|
Suspension |
|
|
Front: |
Spring-supported, kingpin-style front suspension with composite upper & lower suspension arms and steering blocks |
|
Rear: |
Conventional rear pod, adjustable via pivot-ball links, controlled by side tubes |
|
Rear Shock: |
Central adjustable oil-filled shock absorber |
|
Geometry |
|
|
Ride Height: |
Adjustable front + rear |
|
Camber: |
Adjustable front |
|
Front Caster (Static): |
1–14.5° static adjustable static caster |
|
Front Caster (Reactive): |
2.5–7.5° adjustable reactive caster |
|
Track-width: |
Adjustable front + rear |
|
Toe: |
Adjustable front |
|
Downstop: |
Adjustable rear |
|
Ackermann: |
Adjustable with shims and servo position |
|
Steering: |
Direct linkage between steering servo saver and steering blocks |
|
Balance: |
Front/rear weight balance adjustable vi
